Technical Specifications

C1TH-AS

1 Ton/Hour Water Chiller

Model Name:

Water Cooling Capacity:

Water Inlet Temperature:

Water Reduced Temperature:

Water type:

Water Flow:

Power Supply:

Refrigeration Type:

Machine Diemensions(L*W*H):

Total Unit Weight:

Compressor Type:

Compressor Brand:

Compressor Power:

Compressor Capacity Control:

Condenser Type:

Air Flow:

Maximum Pressure HP:

Maximum Presssure LP:

Pump Motor Power-3 bar:

Nominal Current:

Max. Current:

Total Electricity Consumption:

*: We produce different voltage and frequency values ​​​​as an option.

C1TH-AS

24 TONS/DAY

34°C

7°C

FRESH WATER

6,9 m³/H

3P / 360-415V / 50HZ*

FREON R407C

2450*1100*1465 mm

675 kg

SCROLL COMPRESSOR

DANFOSS

11 kW

%100

3*Q500 AIR

24.000 m³/H

30 BAR

16 BAR

2,2 kW

29,3 A

52 A

15,45 kW
