Technical Specifications

Model Name:

Water Cooling Capacity:

Water Inlet Temperature:

Water Reduced Temperature:

Water type:

Water Flow:

Power Supply:

Refrigeration Type:

Machine Diemensions(L*W*H):

Total Unit Weight:

Compressor Type:

Compressor Brand:

Compressor Power:

Compressor Capacity Control:

Condenser Type:

Air Flow:

Maximum Pressure HP:

Maximum Presssure LP:

Pump Motor Power-3 bar:

Nominal Current:

Max. Current:

Total Electricity Consumption:

*: We produce different voltage and frequency values ​​​​as an option.

C10TH-AS

240 TONS/DAY

30°C

7°C

FRESH WATER

56,2 m³/H

3P / 360-415V / 50HZ*

FREON R407C

4330*2250*2740 mm

2950 kg

SCREW COMPRESSOR

BITZER

98,3 kW

%25-%50-%75-%100

6*Q800 AIR

132.000 m³/H

30 BAR

16 BAR

7,5 kW

171,8 A

268,8 A

106,7 kW
